Features:
• Coarse and fine controls for voltage and current.
• Continuously monitor output current and voltage on two large easy to read display.
• Overload and reverse polarity protection.
• CV / CC operation.
• Excellent regulation and low ripple characteristics.
| Model |
PS - 303TD |
PS - 305TD |
| Adjustable Output Voltage (CV) |
0 - 30V |
0 - 30V |
| Adjustable Output Current (CC) |
0 - 3A |
0 - 5A |
| Voltage Line Regulation ±10% |
≤ 0.01% + 3mV |
≤ 0.01% + 3mV |
| Voltage Load Regulation
(no load to full load) |
≤ 0.01% + 3mV |
≤ 0.01% + 3mV |
| Ripple & Noise |
≤ 1mVrms |
≤ 1mVrms |
| Adjustable Current Range |
5% to 100% |
5% to 100% |
| Current Line Regulation ±10% |
≤ 0.2% + 3mA |
≤ 0.2% + 3mA |
| Current Load Regulation |
≤ 0.2% + 3mA |
≤ 0.2% + 3mA |
| Display |
2 x 3 digital LED display |
2 x 3 digital LED display |
