Specifications:
• Constant output voltage range (CV)
• Dual 0-30V continuously variable with fine adjustable for model: 8102 and 8103.
• Load regulation: ≤ 0.01% + 3mV.
• Line regulation: ≤ 0.01% + 3mV.
• Recovery time: ≤ 100ns typical.
• Ripple voltage: Peak to peak ≤ 2m Vrms; ≤ 1mV.
• Temp. coefficient: 5mV / °C typical.
• Constant current range (CC): (3 Amp for model: 8102; 5 Amp for model: 8103)
• Adjustable current limit:
• 5% to 100%, 0.1A to 3A (model: 8102).
• 5% to 100%, 0.1A to 3A (model: 8102).
• 5% to 100%, 0.1A to 5A (model: 8103).
• Current line regulation: ≤ 0.2% + 3mA, load regulation: ≤ 0.2% + 3mA.
• Ripple current: ≤ 3m Arms.
• Output range: 0 to rating current continuously adjustable.
• Protection: CC / CV indicating lamp
• Protection against reverse polarity, over voltage, short circult, overload protection fully adjustable, current limiting and fuse primary protection.
•
• Meter: Built-in type, analog indicator, voltmeter x 2 pcs and ammeter x 2 pcs, ±2.5% of full scale.
• Operation mode: The unit can be operated either as two entirely independent single power supply, two separate DC voltage, or combined in tracking mode to produce equal dual (+) and (-) power supply. Meanwhile, both of two models 8102 and 8103 can be switchable automatically Series / Parallel operation as well.
Model |
Constant Voltage (CV) |
Constant Current (CC) |
Triple Fixed Output 5V / 3A |
Series & Parallel |
8102 |
±0 - 30VDC |
0-3A |
Yes |
Yes |
8103 |
±0 - 30VDC |
0-5A |
Yes |
Yes |
